5-Port Gigabit Easy Smart SwitchTL-SG105E

• 5 10/100/1000Mbps RJ45 ports
• Plug and play, with no configuration required
• Durable metal housing for physical robustness
• Easy management through the web interface or standalone Windows utility
• Green technology reduces power consumption

• HARDWARE FEATURES
  Standards and Protocols	IEEE 802.3i IEEE 802.3u IEEE 802.3ab IEEE 802.3x IEEE 802.1q IEEE 802.1p
  Interface	5 10/100/1000Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX
  Network Media	10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)
  Fan Quantity	Fanless
  Power Supply	External Power Adapter(Output: 9VDC/0.6A)
  Dimensions ( W x D x H )	3.9 x 3.9 x 1.0 in. (100 x 98 x 25 mm)
  Max Power Consumption	2.7W
  Max Heat Dissipation	9.1 BTU/h

  PERFORMANCE
  Packet Forwarding Rate	7.4Mpps
  MAC Address Table	2K
  Packet Buffer Memory	1Mb
  Jumbo Frame	15KB

  SOFTWARE FEATURES
  Quality of Service	Port-based QoS 802.1p/DSCP QoS with 4 priority queues Rate Limit Storm Control
  L2 Features	IGMP Snooping V1/V2/V3 Static Link Aggregation Port Mirroring Cable Diagnostics Loop Prevention
  VLAN	Up to 32 VLANs simultaneously (out of 4K VLAN IDs) MTU/Port/Tag VLAN
  Transmission Method	Store-And-Forward

  OTHERS
  Certification	FCC, CE RoHS
  Package Contents	TL-SG105E Power Adapter Installation Guide Rubber Feet
  System Requirements	Microsoft® Windows® for management utility
  Environment	Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
