| รายละเอียดสินค้า |
| HARDWARE FEATURES |
| Standards and Protocols |
• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP |
| Interface |
• 1× 2.5G RJ45 WAN Port
• 1× 2.5G RJ45 WAN/LAN Port
• 1× Gigabit SFP WAN/LAN Port
• 4× Gigabit RJ45 WAN/LAN Ports
• 1× USB 2.0 Port (Supports USB storage, and LTE backup with LTE dongle) |
| Network Media |
• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
• 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
• 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
• 2500BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
| Fan Quantity |
Fanless |
| Button |
Reset Button |
| Power Supply |
12V/1.5A Adapter |
| PoE Budget |
- |
| Flash |
128MB NAND |
| DRAM |
1 GB DDR4 |
| LED |
PWR, SYS, SFP, USB, WAN (Speed, Link/Act), LAN (Speed, Link/Act) |
| Dimensions ( W x D x H ) |
8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) |
| Protection |
4 kV surge protection |
| Enclosure |
Steel |
| Mounting |
Desktop/Wall Mounting |
| Max Power Consumption |
14.2 W (with USB2.0 connected)
7.1 W (without USB2.0 connected) |
| PERFORMANCE |
| Concurrent Session |
500,000 |
| New Sessions /Second |
4,200 |
| NAT (Static IP) |
2364.45 Mbps / 2343.28 Mbps |
| NAT(DHCP) |
2364.24 Mbps / 2326.21 Mbps |
| NAT(PPPoE) |
2350.93 Mbps / 2125.83 Mbps |
| NAT (L2TP) |
1249.04 Mbps / 831.12 Mbps |
| NAT (PPTP) |
1169.23 Mbps / 1175.52 Mbps |
| IPsec VPN Throughput |
ESP-MD5-AES256: 537.12 Mbps
ESP-SHA1-AES256: 754.65 Mbps |
| L2TP VPN Throughput |
Unencrypted: 1442.65 Mbps
Encrypted: 346.43 Mbps |
| SSL VPN Throughput |
142.99 Mbps |
| 66 Byte Packet forwarding rate |
1832.69 Mbps / 1741.84 Mbps |
| 1,518 Byte Packet forwarding rate |
2461.18 Mbps / 2457.32 Mbps |
| BASIC FUNCTIONS |
| WAN Connection Type |
• IPv4_Static IP
• IPv4_Dynamic IP
• IPv4_PPPOE
• IPv4_L2TP
• IPv4_PPTP
• IPv6_PPP
• IPv6_DHCPv6
• IPv6_Static IP
• IPv6_6in4
• IPv6_Pass-Through
• Mobile Broadband: 4G/3G modem for backup via USB port |
| MAC Clone |
Modify WAN/LAN MAC Address† |
| DHCP |
• DHCP Server/Client
• DHCP Address Reservation
• Multi-IP Interfaces*
• Multi-Net DHCP* |
| IPv6 |
WAN Connection |
| VLAN |
802.1Q VLAN |
| IPTV |
IGMP v2/v3 Proxy |
| ADVANCED FUNCTIONS |
| Advanced Routing |
• Static Routing
• Policy Routing |
| Bandwidth Control |
• IP/Port-based Bandwidth Control
• Guarantee & Limited Bandwidth |
| Load Balance |
• Intelligent Load Balance
• Application Optimized Routing
• Link Backup (Timing§, Failover)
• Online Detection |
| NAT |
• One-to-One NAT§
• Multi-Net NAT
• Virtual Server
• Port Triggering§
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG
• UPnP |
| Security |
• Attack Defense:
TCP/UDP/ICMP Flood Defense
Block TCP Scan (Stealth FIN/Xmas/Null)
Block Ping from WAN
• Filtering
Web Group Filtering
URL Filtering
Web Security
• ARP Inspection:
Sending GARP Packets
ARP Scanning
IP-MAC Binding
• Access Control
Source/Destination IP Based Access Control |
| Session Limit |
IP-based Session Limit |
| VPN |
| IPsec VPN |
• 100 IPSec VPN Tunnels
• LAN-to-LAN, Client-to-LAN
• Main, Aggressive Negotiation Mode
• DES, 3DES, SHA1, AES128, AES192, AES256 Encryption Algorithm
• IKEv1/v2
• MD5, SHA1 Authentication Algorithm
• NAT Traversal (NAT-T)
• Dead Peer Detection (DPD)
• Perfect Forward Secrecy (PFS) |
| PPTP VPN |
• PPTP VPN Server
• PPTP VPN Clients (12)
• 60 Tunnels (Shared with L2TP)
• PPTP with MPPE Encryption |
| L2TP VPN |
• L2TP VPN Server
• L2TP VPN Clients (12)
• 60 Tunnels (Shared with PPTP)
• L2TP over IPSec |
| OpenVPN |
• OpenVPN Server
• OpenVPN Clients (6)
• 66 OpenVPN Tunnels* |
| SECURITY |
| Filtering |
WEB Group Filtering§
URL Filtering
Web Security§ |
| ARP Inspection |
• Sending GARP Packets§
• ARP Scanning§
• IP-MAC Binding§ |
| Attack Defense |
• TCP/UDP/ICMP Flood Defense
• Block TCP Scan (Stealth FIN/Xmas/Null)
• Block Ping from WAN |
| Access Control |
Source/Destination IP Based Access Control |
| AUTHENTICATION |
| Web Authentication |
• No Authentication
• Simple Password*
• Hotspot (Local User/Voucher* /SMS*/Radius*)
• External Radius Sever
• External Portal Sever* |
| MANAGEMENT |
| Omada App |
Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management |
• Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller |
| Cloud Access |
Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller. |
| Service |
Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe) |
| Maintenance |
• Web Management Interface
• Remote Management
• Export & Import Configuration
• SNMP v1/v2c/v3*
• Diagnostics (Ping & Traceroute)§
• NTP Synchronize§
• Syslog Support |
| Zero-Touch Provisioning |
Yes. Requiring the use of Omada Cloud-Based Controller. |
| Management Features |
• Automatic Device Discovery
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration
• ZTP (Zero-Touch Provisioning) |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
• ER707-M2
• Power Adapter
• Quick Installation Guide |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux |
| Environment |
• Operating Temperature: 0–40 ℃ (32–104 ℉);
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% non-condensing |
|
