Console ports
|
|
RJ45 Ethernet
|
1
|
1
|
1
|
1
|
|
USB mini-B
|
1
|
1
|
1
|
1
|
|
USB-A port for storage and Bluetooth console
|
1
|
1
|
1
|
1
|
|
Memory and processor
|
|
CPU
|
ARMv7 800 MHz
|
ARMv7 800 MHz
|
ARMv7 800 MHz
|
ARMv7 800 MHz
|
|
DRAM
|
512 MB
|
512 MB
|
512 MB
|
512 MB
|
|
Flash memory
|
256 MB
|
256 MB
|
256 MB
|
256 MB
|
|
Performance
|
|
Forwarding bandwidth
|
10 Gbps
|
18 Gbps
|
1G: 28 Gbps
|
1G: 52 Gbps
10G: 88Gpbs
|
|
10G: 64 Gbps
|
|
Switching bandwidth
|
20 Gbps
|
36 Gbps
|
1G: 56 Gbps
10G: 128 Gbps
|
1G: 104 Gbps
10G: 176 Gbps
|
|
Forwarding rate
(64‑byte L3 packets)
|
14.88 Mpps
|
26.78 Mpps
|
41.67 Mpps
|
77.38 Mpps
|
|
Unicast MAC addresses
|
16000
|
16000
|
16000
|
16000
|
|
IPv4 unicast direct routes
|
512
|
512
|
512
|
512
|
|
IPv4 unicast indirect routes
|
256
|
256
|
256
|
256
|
|
IPv6 unicast direct routes
|
414
|
414
|
414
|
414
|
|
IPv6 unicast indirect routes
|
128
|
128
|
128
|
128
|
|
IPv4 static routes
|
16
|
16
|
16
|
16
|
|
IPv6 static routes
|
16
|
16
|
16
|
16
|
|
IPv4 multicast routes and IGMP groups
|
1024
|
1024
|
1024
|
1024
|
|
IPv6 multicast groups
|
1024
|
1024
|
1024
|
1024
|
|
IPv4/MAC security ACEs
|
384
|
384
|
384
|
384
|
|
IPv6 security ACEs
|
256
|
256
|
256
|
256
|
|
Maximum active VLANs
|
256
|
256
|
256
|
256
|
|
VLAN IDs available
|
4094
|
4094
|
4094
|
4094
|
|
IPv4 Static Routes
|
16
|
16
|
16
|
16
|
|
IPv6 Static Routes
|
16
|
16
|
16
|
16
|
|
Maximum STP instances
|
64
|
64
|
64
|
64
|
|
Maximum SPAN sessions
|
4
|
4
|
4
|
4
|
|
MTU-L3 packet
|
9198 bytes
|
9198 bytes
|
9198 bytes
|
9198 bytes
|
|
Jumbo Ethernet frame
|
10,240 bytes
|
10,240 bytes
|
10,240 bytes
|
10,240 bytes
|
|
MTBF in hours (data)
|
2,448,133
|
2,416,689
|
2,412,947
|
1,370,769
|
|
MTBF in hours (PoE)
|
315,044
|
313,496
|
909,838
|
437,970
|
|
Environment
|
|
Operating temperature
|
|
Up to 5,000 ft (1500 m)
|
23ºF to 113ºF
(–5ºC to 45ºC)
|
23ºF to 113ºF
(–5ºC to 45ºC)
|
23ºF to 113ºF
(–5ºC to 45ºC)
|
23ºF to 113ºF
(–5ºC to 45ºC)
|
|
WS-C2960L-16PS-LL has maximum operating temperature of 40°C (up to 5,000 ft) and 35°C (up to 10,000 ft).
|
|
Up to 10,000 ft (3000 m)
|
23ºF to 104ºF
(–5ºC to 40ºC)
|
23ºF to 104ºF
(–5ºC to 40ºC)
|
23ºF to 104ºF
(–5ºC to 40ºC)
|
23ºF to 104ºF
(–5ºC to 40ºC)
|
|
Operating altitude
|
10,000 ft (3000 m)
|
10,000 ft (3000 m)
|
10,000 ft (3000 m)
|
10,000 ft (3000 m)
|
|
Operating relative humidity
|
5% to 90% at 40ºC
|
5% to 90% at 40ºC
|
5% to 90% at 40ºC
|
5% to 90% at 40ºC
|
|
Storage temperature
|
–13º to 158ºF
(–25º to 70ºC)
|
–13º to 158ºF
(–25º to 70ºC)
|
–13º to 158ºF
(–25º to 70ºC)
|
–13º to 158ºF
(–25º to 70ºC)
|
|
Storage altitude
|
15,000 ft (4500 m)
|
15,000 ft (4500 m)
|
15,000 ft (4500 m)
|
15,000 ft (4500 m)
|
|
Storage relative humidity
|
5% to 95% at 65ºC
|
5% to 95% at 65ºC
|
5% to 95% at 65ºC
|
5% to 95% at 65ºC
|
|
Storage altitude
|
Note: Minimum ambient temperature for cold start is 0°C (32°F).
|
|
Electrical
|
Data
|
PoE
|
Data
|
PoE
|
Data
|
PoE
|
Data
|
PoE
|
|
Voltage (auto ranging)
|
110 to 220V AC in
|
110 to 220V AC in
|
110 to 220V AC in
|
110 to 220V AC in
|
110 to 220V AC in
|
110 to 220V AC in
|
110 to 220V AC in
|
110 to 220V AC in
|
|
Frequency
|
50 to 60 Hz
|
50 to 60 Hz
|
50 to 60 Hz
|
50 to 60 Hz
|
50 to 60 Hz
|
50 to 60 Hz
|
50 to 60 Hz
|
50 to 60 Hz
|
|
Current
|
0.13A to 0.22A
|
0.22A to 0.27A
|
0.16A to 0.26A
|
0.24A to 0.28A
|
0.20A to 0.33A
|
0.21A to 0.26A
|
0.29A to 0.48A
|
0.37A to 0.64A
|
|
Power rating
(maximum consumption)
|
0.04 kVA
|
0.11 kVA
|
0.05 kVA
|
0.19 kVA
|
0.06 kVA
|
0.24 kVA
|
0.09 kVA
|
0.48 kVA
|
|
Power consumption (watts)
|
|
0% traffic
|
13.0
|
19.9
|
14.9
|
21.9
|
1G: 16.5
|
1G: 17.52
|
1G: 24.36
|
1G: 27.24
|
|
10G: 17.04
|
10G: 16.68
|
10G: 25.8
|
10G: 27
|
|
10% traffic
|
14.8
|
22.0
|
19.3
|
27.1
|
1G: 23.04
|
1G: 24
|
1G: 33
|
1G: 39.24
|
|
10G: 22.92
|
10G: 23.16
|
10G: 38.04
|
10G: 39.12
|
|
100% traffic
|
14.9
|
22.0
|
19.3
|
27.1
|
1G: 23.64
|
1G: 24
|
1G: 33.6
|
1G: 40.32
|
|
10G: 23.64
|
10G: 23.76
|
10G: 39.36
|
10G: 40.56
|
|
Weighted average
|
14.2
|
21.3
|
17.8
|
25.4
|
1G: 21.06
|
1G: 21.84
|
1G: 30.32
|
1G: 35.6
|
|
10G: 21.2
|
10G: 21.2
|
10G: 34.4
|
10G: 35.56
|
|
|
Note: The wattage rating on the power supply does not represent actual power draw. It indicates the maximum power draw possible by the power supply. This rating can be used for facility capacity planning. For PoE switches, cooling requirements are smaller than total power draw because a significant portion of the load is dissipated in the endpoints.
|
|
Acoustic noise (48-port PoE only)
|
|
Sound pressure
|
LpA (typical)
|
35 dB
|
|
LpAD (maximum)
|
39 dB
|
|
Sound power
|
LwA (typical)
|
4.8 B
|
|
LwAD (maximum)
|
5.2 B
|
|
Note: Bystander positions operating mode at 77°F (25°C) ambient.
|
|
Safety and compliance
|
|
Safety
|
UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1
|
|
EMC: emissions
|
47CFR Part 15 (CFR 47) Class A, AS/NZS CISPR22 Class A, CISPR22 Class A, EN55022 Class A, ICES003 Class A, VCCI Class A, EN61000-3-2, EN61000-3-3, KN22 Class A, CNS13438 Class A
|
|
EMC: immunity
|
EN55024 (including EN 61000-4-5), CISPR24, EN300386, KN24
|
|
Environmental
|
Reduction of Hazardous Substances (RoHS) including Directive 2011/65/EU
|
|
Telco
|
Common Language Equipment Identifier (CLEI) code
|
