GS510TP-100EU ProSAFE® 8-port Gigabit PoE Smart Managed Switch with 2 Gigabit SFP Ports

Administrative Switch Management
• IEEE 802.1Q static VLAN (64 groups, static)
• IEEE 802.1p Class of Service (CoS)
• Port-based QoS • DSCP-based QoS
• DiffServ • IEEE802.3ad link aggregation (manual or LACP)
• IEEE 802.1D Spanning Tree Protocol (STP)
• IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
• IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
• IEEE 802.1ab Link Layer Discovery Protocol (LLDP)
• LLDP-MED • SNMP v1, v2c, v3
• RFC 1213 MIB II
• RFC 1643 Ethernet interface MIB
• RFC 1493 bridge MIB
• RMON group 1, 2, 3, 9
• RFC 2131 DHCP client
• Voice VLAN
• Auto-VOIP
• DHCP Filtering
• Auto denial-of-service (DoS) protection
• HTTP and HTTPS
• Ping and traceroute
• Power saving when link down
• IEEE 802.1x (MD5)
• Port-based security by locked MAC addresses
• IP and MAC ACL
• Storm control for broadcast, multicast and unknown unicast packets
• IGMP snooping v1/v2/v3
• Protected Port • PoE Timer
• Port-based ingress and egress rate limiting
• SNTP
• Port mirroring support (many to one)
• Web-based configuration
• Configuration backup/restore
• Password access control
• RADIUS Support
• TACACS+ support
• Syslog
• Firmware upgradeable Performance Specifications
• Forwarding modes: Store-and-forward
• Bandwidth: 20Gbps
• Network latency: <4μs for 64-byte frames in store-and-forward mode for 1000Mbps to 1000Mbps transmission
• Buffer memory: 512KBytes per system
• Address database size: 4,000 media access control (MAC) addresses per system
• Addressing: 48-bit MAC address
• Mean time between failures (MTBF): 458,124 hours at 25C (~52.3 years)
• Acoustic noise: <38dBA
